Classic Oak

Classic Oak Collection

Click Any Image to Enlarge

Classic Oak Cabinet Specifications

• Style: Raised Square (5 piece decor header)

• Face Frame: 3/4” Solid Wood

• Door Frame: 3/4” Solid Oak

• Door Center: MDF with Oak Veneer (MDF is used to avoid cracking/warping)

• Sides: 1/2" A-Grade plywood with wood veneer

• Top & Bottom (Wall): 1/2" A-Grade plywood with wood veneer

• Bottom (Base): 1/2" A-Grade plywood with wood veneer

• Back Panel: 1/2" Picture Frame recess style

• Shelves: 3/4 " A-Grade plywood with wood veneer

• Base Cabinet Shelf Depth: 1/2

• Drawer Box: Solid Wood 3/5" sides, Drawer bottom 1/2" plywood, Drawer length 21". Rabbet joint construction, Natural Oak finish.

• Drawer Glides: Epoxy coated metal side mount

• Base Corner Supports: Plastic corner brackets

• Overlay: Full with butt doors

• Hinges: Concealed 6-way adjustable

• Cabinet Interior: Matches door finish

• Center Stile: No center stile on cabinetry 24"W to 36"W

• Assembly Method: Steel Clip

• Finish: Polyurethane Finish

• Toe Kick: 1/2" Plywood

• Installation Rail: 1/2" Plywood

• Wall Cabinet Bottoms Finished (Exterior): Yes

• CARB Compliant: Yes

• Door Hinges: Hinged To The Right By Default. For Wall Cabinets The Face Frame Can Be Flipped. For Base Cabinets Unhinge The Door, Flip It, Screw Holes On The Opposite Side To Re-Hinge, And Then Fill The Original Holes (Touch Up Kit Can Be Purchased For This)

• Toe Kicks Included w/Base Cabinets: Yes

• Sides Panels Finished: Yes

• Installation/Design Note: The full-overlay door style leaves roughly a 1/4" clearance on the edge. If installed directly against a wall or deeper cabinet, the cabinet door will be able to open 90 degrees. For a full opening, a space of at least 1/4" is necessary, a larger space may be needed depending on the decorative hardware used on the cabinets. Cabinet specs are subject to change without notice. *Cabinet measurements are typically converted from metric to inches and manufacturers will commonly round up to the nearest 1/4 inch. This can cause a measurement to be off by a fraction of an inch (less than 1/4") which is within normal industry standards*
