Prefinished Cabinets
- by A.C.T. Building & Remodeling
Merlot Glaze
Basic Kitchen Price - $2026
Raised Panel Door Style with Deep Brown and Red Wood Tones - Stylish Door Panel Detail, Corner Glaze Effect, and Rich Warm Color Make The Merlot Glaze Collection an Elegant Choice. Features Quality Details Including Full Overlay Doors, Dovetail Drawer Construction, and Soft Close Drawer and Doors.
Merlot Glaze Collection
Click Any Image to Enlarge
Merlot Glaze Cabinet Specifications
Style: Raised Square
Face Frame: 3/4" Solid Birch
Door Frame: 3/4” Solid Birch
Door Center: Solid Birch
Sides: 1/2" A-Grade plywood with wood veneer
Top & Bottom (Wall): 1/2" A-Grade plywood with wood veneer
Bottom (Base): 1/2" A-Grade plywood with wood veneer
Back Panel: Full back on bases (3/4" plywood)
Shelves: 3/4 " A-Grade plywood with wood veneer
Base Cabinet Shelf Depth: 1/2
Drawer Box: Solid Wood 17mm (close to 3/4") sides, Drawer bottom 1/2" plywood, Drawer length 21". Dovetail construction, Natural finish.
Drawer Glides: Undermount, full extension with soft closing feature
Base Corner Supports: Wood corner brackets with wood I-beam construction
Overlay: Full with butt doors
Hinges: Concealed 6-way adjustable with Soft Closing Feature
Cabinet Interior: Matches door finish
Center Stile: No center stile on cabinetry 24"W to 36"W
Assembly Method: Steel Clip
Finish: Polyurethane Finish
Toe Kick: 1/2" Plywood
Installation Rail: 1/2" Plywood
Wall Cabinet Bottoms Finished (Exterior): Yes
CARB Compliant: Yes
Door Hinges: Hinged To The Right By Default. For Wall Cabinets The Face Frame Can Be Flipped. For Base Cabinets Unhinge The Door, Flip It, Screw Holes On The Opposite Side To Re-Hinge, And Then Fill The Original Holes (Touch Up Kit Can Be Purchased For This)
Toe Kicks Included w/Base Cabinets: Yes
Sides Panels Finished: Yes
Installation/Design Note: The full-overlay door style leaves roughly a 1/4" clearance on the edge. If installed directly against a wall or deeper cabinet, the cabinet door will be able to open 90 degrees. For a full opening, a space of at least 1/4" is necessary, a larger space may be needed depending on the decorative hardware used on the cabinets. Cabinet specs are subject to change without notice. *Cabinet measurements are typically converted from metric to inches and manufacturers will commonly round up to the nearest 1/4 inch. This can cause a measurement to be off by a fraction of an inch (less than 1/4") which is within normal industry standards*
